背景介绍

之前一直有使用FRP做内网穿透，一般主要用于远程桌面和对外提供http服务进行测试，由于域名备案信息被撤销，原有解析过去的二级域名被拦截了，所以考虑将FRP 服务端部署到一台墙外的服务器上去，搜了一圈没找到之前的部署记录，本次也就只好将安装过程记录备忘了。

安装时间：2023-05-14 15:51

安装

下载最新版本的frp

frp 在GitHub的地址是，

# 进入用户目录
cd /usr/local
# 下载frp 最新版，
wget https://github.com/fatedier/frp/releases/download/v0.48.0/frp_0.48.0_linux_amd64.tar.gz
# 解压
tar -zxvf frp_0.48.0_linux_amd64.tar.gz

配置

打开服务端配置文件

vi /usr/local/frp/frps.ini

参考frps_full.ini,将服务端配置文件(frps.ini)修改为如下内容

[common]
bind_addr = 0.0.0.0
bind_port = 7000
token = TOKEN_INFO

# udp port to help make udp hole to penetrate nat
bind_udp_port = 7001

# if you want to support virtual host, you must set the http port for listening (optional)
# Note: http port and https port can be same with bind_port
vhost_http_port = 80
vhost_https_port = 443

# console or real logFile path like ./frps.log
log_file = ./frps.log

# set dashboard_addr and dashboard_port to view dashboard of frps
# dashboard_addr's default value is same with bind_addr
# dashboard is available only if dashboard_port is set
dashboard_addr = 0.0.0.0
dashboard_port = 7500

# dashboard user and passwd for basic auth protect
dashboard_user = admin
dashboard_pwd = admin

# dashboard TLS mode
dashboard_tls_mode = false

# authentication_method specifies what authentication method to use authenticate frpc with frps.
# If "token" is specified - token will be read into login message.
# If "oidc" is specified - OIDC (Open ID Connect) token will be issued using OIDC settings. By default, this value is "token".
authentication_method = token

# if subdomain_host is not empty, you can set subdomain when type is http or https in frpc's configure file
# when subdomain is test, the host used by routing is test.frps.com
subdomain_host = lan.dev.trswcm.com

自启动

添加自启动文件

vi /etc/systemd/system/frps.service

输入如下内容：

[Unit]
Description=Frp Server Service
After=network.target

[Service]
Type=simple
User=root
Restart=on-failure
RestartSec=5s
ExecStart=/usr/local/frp/frps -c /usr/local/frp/frps.ini

[Install]
WantedBy=multi-user.target

添加可执行权限

chmod +x /etc/systemd/system/frps.service

注册服务

systemctl enable frps.service

当出现如下提示信息后表示注册成功


[root@VM-0-9-centos systemd]# systemctl enable frps.service
Created symlink from /etc/systemd/system/multi-user.target.wants/frps.service to /etc/systemd/system/frps.service.

启动服务

systemctl daemon-reload
systemctl start frps

启动过程有可能会报错，报错的话，请根据错误提示进行相应调整

查看服务状态

systemctl status frps

出现如下截图所示信息则表示已启动成功：

FRP服务端安装并设置开机自启动
